D71210
Key Specs
  Bedroom: 2
  Bathroom: 1
  Area: 71 m2
  Steel: 89S41G350-0.95 mm
  Floor: 1
  Garage: 0
  Structure Weight: 2070 kg
Packages Price
Foundation 70
Architectural Drawings 100
Complete BOQ 70
Framecad drawings & roll forming file 60
Framecad FCP file 40
Full Package 340
  Order Now   Calculate Structure Cost

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.

  Modify This Plan

WHAT'S INCLUDED IN THIS PLAN SET

  • Foundation plan: Typically includes dimensioned foundation plan with footing details
  • Exterior elevations of all four views,
  • Building sections and details as required to construct the individual design
  • Roof plans
  • Gravity and Lateral Analysis and Design using Standard sections
  • Cold-Formed Steel Structural Drawings
  • Cold-Formed Steel Shop Drawings
  • Exact material takeoff for price estimation (by sqm of surface Area)
  • Cold-Formed Steel Connection Design and Details
  • Exact material takeoff for price estimation
  • Hot Rolled Steel as per the Project Requirement
  • Roll Forming File for your framecad machine (If you need complete files for other machines, like HOWICK, PINNACLE, and any other VERTEX BD supported machine, just send us the brand and the model of your machine and the desired plan number to info@lgsfdesign.net, We will respond in few hours with a quotation.)
