SCH1000
3D Structure Model
Description
This LSF (Light Steel Frame) structure covers an area of 1,000 square feet and is designed to function as a school. It will be installed on the rooftop of an existing building in Karachi, Pakistan, providing a modern, efficient, and space-saving educational facility. Its lightweight yet durable design ensures structural integrity while accommodating the specific needs of an urban learning environment.
Key Specs
Title :
Location :
Area :
SCH1000
Pakistan93 m2
Additional Details
Heavy Steel :
Roll Former Machine :
Longest Member :
Time to Design :
No
Framecad
5.00 m
1 Day
Load Conditions
Designing Code :
Characteristic Value of Snow Load :
Fundamental Basic Wind Velocity :
Basic Velocity Pressure :
Reference Value of Peak Ground Acceleration :
IBC 2021
0.00 kN/m2
45.00 m/s
1.00 kN/m2
0.20 m/s2
