Description
One of the most cost-effective and fastest ways to build a warehouse is to use the LSF system. The project you are looking at is a warehouse measuring 15 x 30 meters, which was produced, installed and completed in two weeks . Now you can buy all the files related to this project at an exceptional price of 700 US dollars.
Project Spec:
Span :15m
Length :30m
Clear Height:5m
wind speed :50 m/s
Steel Section :89 S41
Package Included :
1- Architectural drawings
2- Foundation calculation and drawings
3- Complete Material BOQ
4- Structure drawings
5- Structure BOQ
6- Connections details
7- Engineering report (done by sap 2000)
8- Connection details
9- Framecad detailer File (FCP)
10- Framecad Roll forming File
11- Rendered Photo without Watermark
Key Specs
Title :
Location :
Area :
Price :
WAREHOUSE
United Arab Emirates450 m2
$ 700.0
Additional Details
Heavy Steel :
Time to Design :
No
3 Days
Load Conditions
Designing Code :
Characteristic Value of Snow Load :
Fundamental Basic Wind Velocity :
Basic Velocity Pressure :
Reference Value of Peak Ground Acceleration :
IBC 2021
0.00 kN/m2
40.00 m/s
1.00 kN/m2
0.00 m/s2
