3D Structure Model
Click here to view the 3D
model online or download .wrl or .ifc file
EXPLORE 3D STRUCTURE VISUALIZATION
Key Specs
Title :
Location :
Area :
Bedroom :
Bathroom :
BASIR
United Arab Emirates156 m2
2
4
Additional Details
Heavy Steel :
Roll Former Machine :
Longest Member :
Time to Design :
No
FRAMECAD
4.00 m
5 Hrs
Load Conditions
Designing Code :
Characteristic Value of Snow Load :
Fundamental Basic Wind Velocity :
Basic Velocity Pressure :
Reference Value of Peak Ground Acceleration :
IBC 2021
0.00 kN/m2
44.00 m/s
1.00 kN/m2
0.00 m/s2
