TRIPLEX360
3D Structure Model
Description
This project is a 360 m² Light Steel Frame structure composed of three separate residential units, designed for construction in the United States. Each unit is laid out to meet modern living standards, and the overall building is engineered for strength, efficiency, and high performance.
The LSF system shown in the model offers precise manufacturing, fast erection on site, and excellent durability. The truss arrangements, load-bearing wall configurations, and continuous framing lines create a stable and lightweight structure that performs exceptionally well under American building codes.
The design demonstrates how multi-unit housing can be delivered with clean structural logic, reduced material waste, and improved energy efficiency. This type of layout is especially suitable for developers seeking a balance between speed of construction and long-term resilience.
Key Specs
Title :
Location :
Area :
Bedroom :
Bathroom :
TRIPLEX360
United States of America360 m2
3
2
Additional Details
Heavy Steel :
Roll Former Machine :
Longest Member :
Time to Design :
No
Framecad
7.00 m
2
Load Conditions
Designing Code :
Characteristic Value of Snow Load :
Fundamental Basic Wind Velocity :
Basic Velocity Pressure :
Reference Value of Peak Ground Acceleration :
IBC 2021
0.50 kN/m2
55.00 m/s
1.60 kN/m2
0.20 m/s2
