3D Structure Model
Description
The proposed structure is a warehouse designed using LSF profiles. The building has a clear span of 10 m, a total length of 30 m, and a minimum eave height of 3 m. The estimated structural weight of the LSF system is approximately 24 kg/m².
The structural design has been carried out for a snow load of 1.2 kN/m² and a basic wind speed of 110 km/h, in accordance with the applicable design standards and conditions for Romania.
The LSF framing system consists of cold-formed steel C-sections with dimensions of C140, C200, and C300.
The structural modeling and analysis were performed using Tekla and SAP2000 software.
Key Specs
Title :
Location :
Area :
Price :
S1030
Romania300 m2
$ 670.0
Additional Details
Heavy Steel :
Roll Former Machine :
Longest Member :
Time to Design :
No
Dahezb
4.70 m
5 Days
Load Conditions
Designing Code :
Characteristic Value of Snow Load :
Fundamental Basic Wind Velocity :
Basic Velocity Pressure :
Reference Value of Peak Ground Acceleration :
IBC 2021
1.20 kN/m2
30.00 m/s
0.54 kN/m2
0.20 m/s2
